Key Features
Product Features
OVERVIEW
DESCRIPTION
- 90hp V-twin, liquid cooled 8-valve engine
- High strength FEA optimized one-piece HSLA steel frame
- AA arm front suspension w/fully adjustable gas shocks
- QUADLINK rear suspension w/fully adjustable gas shocks
- RIDEVISION high-intensity LED headlights & DRL
- Full underside protective skid plates
- Electronic Throttle Control
- PULSE multifunction color TFT display w/two view modes
- CVTech transmission
- Quick-Ratio variable Electronic Power Steering
- Ground clearance: 12.2″
- 14″ alloy wheels, 27″ radial tires, beadlock rims
- 2″ hitch receptacle, 550lb tow capacity
- 3500lb winch
- Roof, tilt steering, LED taillights, 220lb cargo rack capacity, DC power & USB outlets
- Engine Type: V-twin cylinder, liquid cooled, 4-stroke, SOHC, 8-valve
- Engine Displacement: 963 cc
- Fuel System: Bosch EFI
- Max Power Output: 90 HP @ 7750 RPM
- Max Torque: 64 ft. lbs. @ 6750 RPM
- Cooling System: Liquid cooled
- Starter: Electric
- Transmission: CVTech® Automatic P/R/N/H/L
- Wheels (front): 14″ aluminum alloy
- Wheels (rear): 14″ aluminum alloy
- Tires (front): 27 x 9-14″
- Tires (rear): 27 x 11-14″
- Suspension (front): Double A-Arm Independent
- Rims: Beadlock
- Suspension (rear): QuadLink™ trailing arm independent
- Shock Absorber (front/rear): High-pressure gas, compression, and rebound adjustable
- Brakes (front/rear): Hydraulic
- Length: 118″
- Width: 60″
- Height: 71″
- Wheelbase: 90″
- Ground Clearance: 12.2″
- Curb Weight: 1,499 lbs.
- Hitch/Receiver: 2″
- Winch: 3,500 lbs.
WARNING: CFMOTO recreational vehicles are intended for off-road use only, and can be hazardous to operate. Read Owner’s Manual and all product labels before operating. Never operate on paved roads. Operators and passengers must wear a helmet, eye protection and protective clothing. Operators must be at least 16 years old with a valid driver’s license. Passengers, if permitted, must be at least 12 years old. Always use seat belts, cab netting and doors (if equipped). Never operate under the influence of alcohol or drugs. Avoid excessive speed and sharp turns, and never engage in stunt driving. Check state and local laws before operating on trails. Take a safety training course before operating. Contact your CFMOTO dealer for more information, call the ATV Safety Institute at 1-800-887-2887, or go to www.atvsafety.org.
Engine Type: V-twin cylinder, liquid cooled, 4-stroke, SOHC, 8-valve
Displacement: 963 cc
Cooling: Liquid
Fuel System: Bosch EFI
Front Suspension: Double A-Arm Independent
Front Brakes: Hydraulic
Front Tire: 27 x 9-14 in.
Rear Suspension: QuadLink™ trailing arm independent
Rear Tire: 27 x 11-14 in.
Dry Weight: 1,499 lb.
Wheelbase: 90 in.
Ground Clearance: 12.2 in.
Transmission CVTech® Automatic P/R/N/H/L
